Using the Visual Studio Code editor

Visual Studio Code is an open-source, cross-platform text editor. Scala is supported via an official plugin. This is a short guide for installing and using Visual Studio Code (VS Code) for working on programming assignments in the course.

(The exercises should work well with other IDE’s or build systems that support sbt builds, so you are free to use your own set-up if you like, although the course staff might not be able to help you with it.)

---

On Aalto Linux computers

VS Code is accessible as a software module on the Aalto workstations found in the computer labs (or on a virtual desktop using Aalto VDI),

To start Code on an Aalto Linux workstation do the following:

1. Open a terminal

2. (On VDI remote desktops only) Authenticate to make vscode (and other) software module available: kinit

3. Load the vscode module by the command: module load vscode/a1120

4. Start VS Code by the command: code

Do not forget the /a1120 part of the module name. It denotes the version of VS Code used in this course, and contains tweaks to make the Scala plugins work better on VDI. If you simply load vscode then you will have the vanilla version. (If you happen to load the default version, you can unload it with the command module unload vscode).

The VS Code editor should now open, and you are ready to start working. If this is the first time you start VS Code for the course, make sure to also do the steps under `Setup`_ below to install Metals and properly configure Code.

Warning

When working on Aalto Linux computers do not place the assignment projects under any of the ‘standard’ folders Desktop, Downloads, or Documents (or any other linked folder)! Due to an open issue, compilation messages and errors are not handled correctly. Instead, your projects under a sub-directory you have created in your home directory.

Installation on personal computer

If you would like to use your own computer to work on the exercises you need to install VS Code, Java, and sbt:

First things first

• Install JDK 11

  • Windows: download and run Java 11 installer at adoptium.net

  • MacOS: use package manager sdkman or download and run installer from adoptium.net

    • If you use the installer from adoptium, make sure to pick the aarch64 architecture if you have the newer M1/M2 chipset.

    • If you use sdkman:

      1. Follow instructions to install sdkman,

      2. Run sdk install java 11.0.18-tem. (sdk can also be used to install sbt, see below.)

  • Ubuntu Linux: install package openjdk-11-jdk

  • Other Linux distributions: consult your package manager

• Install sbt

  (Note: sbt is needed if you like to open a Scala console, Code + Metals will usually work without it)

  • MacOS: instructions Note: several options are given for Mac OS in the link above, the most straight forward is probably to install a package manager, such as sdkman, first if you are OK with that. Then you can do the following:

    1. Follow instructions to install sdkman, (unless you already have it)

    2. run sdk install sbt in your terminal to install sbt.

  • Windows 11: download and run the msi installer

  • Linux: instructions

macOS

• Download the .zip file from https://code.visualstudio.com/ and extract it

• Optional: move the now decompressed VS Code application into the Applications folder

Linux

• Ubuntu: Install “Visual Studio Code” in “Ubuntu Software”

• Debian-based distributions (Debian, Ubuntu, etc.): Download the .deb file and run the installer

Windows 10 & 11

• Download the installer from https://code.visualstudio.com/ and run it.

---

Setup

1. Run the VS Code application, select the extensions tab on the left-hand side, or in the menu View → Extensions

2. In the search field, search for “metals”, choose Scala (Metals), and hit install. This will install the Metals language server which adds IDE-like features such as code actions, completion, and syntax and error highlighting, among other things that make the development process concise and convenient.

Installing the Scala (Metals) extension.

Note

Scala (Metals) is incompatible with the VS Code extensions Scala (sbt) and Scala Language Server. Under Windows 10/11 it may also conflict with the WSL extension. If you have used VS Code previously and have any of these extensions installed, make sure to uninstall or disable them for the assignment workspaces.

---

Workflow

• Download an exercise sbt source package from A+ and extract an assignment directory

Warning

If you are using VS Code on an Aalto Workstation do not place the assignment projects under any of the “standard” folders Desktop, Downloads, or Documents (or any other linked folder). Due to an open issue, compilation errors are not handled correctly. Instead, place them under some sub-directory you have created in your home directory.

• Navigate to the menu bar, proceed with File → Open Folder…, and select the extracted sbt assignment folder



  Open the assignment folder containing the project and src folders (and the file build.sbt, if you can see it).

• Recent versions of VS Code will show a dialogue asking if you trust the project. You should select Yes, I trust the authors to be able to build and debug the exercise. (If you pick the No option by mistake you can change it later.) If you organise a separate course folder (as you should!) for A1120, tick the box Trust the authors of all files in the parent folder… to prevent this popup every time you import a new exercise.



  If asked, you need to select Yes to trust the exercise and activate the build tools.

Note

Treat trust seriously. Build scripts, such as those of sbt, are often full-fledged scripting languages in themselves, and they have the power to read and write files on your computer. For example to seamlessly install missing libraries and execute components as needed. This is why many modern development tools, such as VS Code and IntelliJ, asks you if you trust a project before it imports a project. Take this seriously. If you are uncertain if you trust the authors of a software project you have just downloaded, it is often safest to choose to open it in a preview-mode first. For this course, however, we hope that you trust the teaching staff sufficiently to import the exercises.

• If this is the first time you open a Scala project VS Code may download and install Metal extension components at this point. This may take a minute or two.

• Next, VS Code will detect the assignment workspace and ask what you want to do with it. Choose Import build, and wait while the assignment is set up; progress is displayed in the blue status bar located at the bottom of the window. (If the pop up disappears, do not worry, you can get it back by clicking on the little ‘bell’ icon furthest to the right in the same blue status bar.)

Select Import build when asked.

Warning

If you do not get prompted to Import the project, make sure you have opened the correct folder or VS Code will not import it as a Scala project. (It needs to be the assignment folder containing the build.sbt file, and the project and src directories.) If this has happened, just close the current folder from the File menu and open the right one.

• Read the provided program code and documentation

• Develop your solution. The places you should insert your code are usually marked with ???



  Develop your solution.

• Some syntax errors will be shown as you type, and the build server will compile your code every time it is saved, so save often

• Compilation errors are indicated in the status bar, in the program code, and the explorer. The full error messages are displayed in the problems tab: View → Problems



  It is hard to miss problems with your code…

• Run tests by opening the corresponding .scala file in the test folder and click on the green ‘play’ ( ▶ ) symbol to the left of the class name. Output will appear in the Debug Console (should appear automatically, otherwise go to View → Debug Console). Note: The test/run links will only appear if your program compiles, so make sure that your code is error-free and saved before testing it.

• Always run the provided unit tests and check if they pass

Note

Unit tests and A+ grading performs different tasks. Just because your code passes all unit tests does not guarantee a full score by the grader. On the other hand, you may not necessarily need to solve all the tasks in an exercise to submit your solution for grading and get some points. Most exercises award points for every individual task, so you can get points from an exercise even if some unit tests fail. (But in the real world for professional programming, never ship code which fails a unit test.)

Running unit tests.

• When you are happy with your solution, submit the required .scala files to A+ for grading (you can drag-n-drop the files from your system’s file manager/explorer in modern browsers; you can also open a system file manager from Code by right-clicking on a file tab and selecting Open containing folder).

Trouble-shooting

The Test and Run links don’t appear in my source code

• First, check that your code is error free and that you have saved it. The links only appear for programs on successful compilation.

• Were you asked to import the project when you opened it?

  • If not, then you may have opened the wrong folder. The most common ‘wrong’ folder is a folder containing the assignment folder (on Windows machines, this can easily happen if the unzip creates a new directory to place the contents in and you choose the outer folder). The result is that the assignment is not recognised as a Scala project. The fix is easy: close the current folder File → Close Folder and open the right one (the one extracted from the zip file containing the “a” directories, and build.sbt).



    The assignment folder (containing build.sbt) must be the top folder you open for the project to be recognised (left). If you open a containing folder (even if it has the same name) it will not be recognised (right). If you are not asked to import the project you have the wrong folder.

  • You were asked to import, but choose not to, or clicked away the pop-up: click on the ‘bell’ icon to bring back the pop-up, or trigger a new import from the BUILD COMMANDS tab (see below), or by closing the folder and opening it again as described above.

• If none of the above, the build server may have crashed. It is uncommon, but can happen.

  1. Go to the Metals tab (the m icon in the vertical tool-bar). Under BUILD COMMANDS click on Restart build server. It will take a few seconds for the build server to come up again, you can see the status in the message-bar.

  2. You can then trigger Metals to re-scan the file for compilation by making a small change (e.g. inserting an empty line) and saving the file.

  3. If the above did not work you can also force a re-import of the project by clicking on Import Build in the same menu.



  The Scala Metals build build commands.

  1. Finally, if the links has stopped working suddenly, it could be that the old build process has crashed. In that case, try to terminate it as described in the next section.

Scala not found

This error happens if you have the Code Runner plugin installed in your workspace. Disable it for the current project and runt code and tests through Metals (see basic tasks for more information about ow to run tests and main programs with Metals).

Java not found

1. Check that you do not have an old version of VS Code (if you have installed it previously and not updated it). If so, update it or reinstall it.

2. If the problem persists:

1. Make sure JDK 11 was properly installed

2. In the extensions tab select the cogwheel for Scala (Metals) and open the settings. Find the Metals: Java Home field and fill in the path to the JDK 11 (in windows use explorer, then right-click in the address-bar and select copy-as-text, then paste this value into the field).

Error message about build server

• Windows 11 : This could be because path to your programming exercise contains spaces. The current release of the Metals build-server does not play nice with all windows 11 paths. Fix: remove the spaces, or install the pre-release of Metals as shown in the next item.

• (Windows, if you have a user name containing ‘special’ characters [such as ä and ö] or spaces [on Win11])

  Sadly, paths are still not always handled properly, and some with non-ASCII characters in their usernames have reported problems under Windows, where the build server crashes. Fix: Start using the pre-release of Metals (2023-02-28), you can do this by clicking on the ‘cogwheel’ of the Metals extension and select Switch to Pre-Release Version. This will give you the developer version which seems to fix the bug. Alternatively switch to using IntelliJ instead.



  Use the Metals pre-release if you have a space in your user name on Windows 11 and are experiencing problems. Click on the ‘cogwheel’ at the Scala (Metals) extension and select Switch to Pre-Release Version.

• Can happen if the wrong, or multiple versions of Java is installed

  1. Make sure JDK 11 was properly installed

  2. In the extensions tab select the cogwheel for Scala (Metals) and open the settings. Find the Metals: Java Home field and fill in the path to the JDK 11 (in windows use explorer, then right-click in the address-bar and select copy-as-text, then paste this value into the field).

• Conflicting extensions

  If you have either of the VS Code extensions Scala (sbt) or Scala Language Server, uninstall or disable that extension.

• A defunct build server process is left on your system

  This could be the case if the build process works initially, but then crashes. In this case it is worth trying to terminate the process and restart VS Code:

  • Shut down Code, then

    • (MacOS/Ubuntu) open a terminal and run pkill java to terminate all java processes

    • (Windows) open the task manager and terminate any running java processes

  • Restart Code. This should create a new build-server process.

• (Windows) Disable WSL for project

  If you have previously used Code for other courses or projects, you may have the WSL (Windows Subsystem for Linux) extension installed. This extension can interfere with Scala (Metals). The solution is to disable the WSL extension for your Scala projects (Extensions, WSL, click the drop-down menu at Disable and select Disable (Workspace), then restart Code.)

• (OneDrive/iCloud): Some (but not all) users keeping their exercise folders on a cloud drive, such as OneDrive or iCloud, have reported issues with the build server. If you do, and experience problems, it can be worth trying to move the exercises to a location that is not actively synchronised with the cloud.

sbt command not found

• If you have started VS Code before installing sbt you need to either restart Code or open a new terminal as a terminal is not aware of programs installed after it was opened.

• (Windows) You may have to add the sbt directory to your system PATH. See e.g. instructions in this post.

Error: code: No such file or directory (Aalto Linux workstation)

• If you get an error message saying code: No such file or directory when trying to run code, then you may have forgotten to load the module properly.

• A successful call to module load vscode/a1120 will print nothing. If you get an error message here, check that you have typed the command correctly.

• If you want to check that the module is loaded you can give the command module list.

Error: the following module(s) are unknown (Aalto Linux workstation)

You have probably forgotten to run kinit (if using a remote desktop).

• You need to run kinit and load the vscode/a1120 module every time you log in to the VDI workstation

• If you get an error message saying Lmod has detected the following error:  The following module(s) are unknown: "vscode/a1120" you may have forgotten to run kinit on VDI

Note

kinit is part of the kerberos suite, a protocol for authentication of network resources. It will ask for your Aalto password in order to provide the extra software modules of which VS Code is a part. In the Aalto computer labs this is done automatically when you log in, but if you connect to a virtual machine you have to do it yourself. This is current Aalto IT policy, however in general, always think twice when somebody asks you to execute a program which asks for your password.

Warning: Code navigation will not work

This is generally nothing to worry about.

Some recent versions of Scala Metals will somewhat annoyingly pop up a warning saying that code navigation will not work because Java sources are not installed when a project is opened although it will work fine for the assignment project. This message can be ignored - you will still be able to navigate and debug the assignment code.

This warning is shown by some versions of Scala Metals and can be ignored.
